12Vdc powered temperature activated audible alarm module. Onboard trimpot to set trigger temperature between 0 and 100°C. Buzzer can be set to activate as an Under or Over temperature alarm using a jumper tab.
The hysteresis range is 1°C so when used as an Over Alarm, the buzzer activates when the temperature sensor is 1°C over the trigger level and turns off when the temperature falls 1°C under.
A separate small temperature probe board is included.
Specifications| Temperature Range | 0 ~ 100°C |
| Hysteresis Range | 1°C |
| Supply Voltage | 12V dc |
| Power Supply Options | Power Supply Module: CFE103 or UK Plug Power Supply: 660.446UK with connector 777.001UK |
| Current Consumption | 50mA max |
| Output | 1 x Onboard buzzer |
| Dimensions | ~ 67 x 45 x15 mm |
| Enclosure | WCAH2855 |
| Weight | 62 grams |
| Product Format | PRE-ASSEMBLED Electronic Module Product Format Info |
