15-Channel Infrared Receiver Module

Velleman VM122 - 15-Channel Infrared Receiver Module

This item is obsolete and no further stocks are available. Please see category links above for alternatives.

Velleman VM122 Electronic Module (Pre-Assembled)
Velleman Modules Range

The pre-assembled VM122 15-Channel Infrared Receiver Module provides 15 open collector outputs and works with VM121 and a number of other products in the range as listed below.

It can be combined with the VM129 8-Channel Relay Card Module to allow control of mains powered equipment.

Also available in SELF-ASSEMBLY Electronic Kit format (Order Code K8050).

Features
  • works together with K6710, K8049, K8051, K8055, K8056, K6714, K6714-16, K2633 and VM121
  • 15 open collector contacts: max. 50V/50mA
  • LED indication for each output
  • multiple IR sensors possible (type : PIC1018SCL connected in parallel)
  • transmitter - receiver range: up to 20m
  • 4 different modes:
    • 15 independent outputs
    • 15 rotary outputs
    • 7 independent outputs & 8 rotary outputs
    • 7 rotary outputs & 8 rotary outputs (independent from each other)
  • 3 addresses allow the use of multiple receivers in one room
Specifications
  • power supply: 8 ~ 14VDC or 2x6 ~ 2x12VAC (150mA)
  • current consumption:
    • all outputs off: 10mA
    • all outputs on: 150mA
  • dimensions: 71 x 114mm (2.8" x 4.5")
  • Product format: PRE-ASSEMBLED Electronic Module Product Format Info
Velleman VM122 DocumentationBuy Velleman VM122 15-Channel Infrared Receiver Module
