2-Channel Multiplex Relay Receiver Module (Latching)

Cebek TL-63 (CTL063) - 2-Channel Multiplex Relay Receiver Module (Latching)
CEBEK TL-63 Electronic Module (Pre-Assembled)
Cebek Electronic Modules

The Cebek TL-63 module is a 2 channel Drive-By-Wire receiver with two Latching Action relay output. It can be operated using a TL-50 or TL-51 transmitter (not included).

The desired relay turns on when the appropriate command signal is received from the transmitter and turns off when a second signal is received.

Screw terminal blocks are used for all connection terminals. An LED indicates the relay status. Power is supplied through the TL-55 booster module (not included)

Specifications
Current Consumption120mA
Output2 x SPDT Relay
Maximum Output
Load (Resistive)
Up to 240Vac or 28Vdc @ 3 Amps max. (Relay Datasheet)
Relay ConnectionsNO, NC, C (Relay FAQ)
Output Channels2
Relay ActionLatching
Board ConnectionsScrew terminal blocks
Dimensions (WxDxH)~ 106 x 62 x 30mm
Weight98g
Product FormatPRE-ASSEMBLED Electronic Module Product Format Info
Item Number:
Cebek TL-63 (CTL063)
Total Price:
£14.26 +VAT, £17.11 Inc
Stock Info:
In Stock (UK Warehouse)
Your Total:
Quantity:
