Infrared Security Beam (Relay Output)

Infrared Security Beam (Relay Output)
Infrared Security Beam (Relay Output)
Infrared Security Beam (Relay Output)
Infrared Security Beam (Relay Output)
AS3130KT - Infrared Security Beam (Relay Output)
Ability Level 2: ModerateProduct Formats Available : Pre-Assembled Module (AS) or
Self-Assembly Electronic Kit ( Soldering Required)

Can be used to set-up an invisible security system using infrared (IR) beams. When the beam is broken (or the power supply cut) the relay is tripped. This can be used to sound a bell, alarm or other device.

It can be used for detecting customers entering a shop or other INDOOR applications. Can also be combined with our LED Counter kit 3129 to count people or other objects as they break the beam. The beam is very powerful and distances over 15 metres can be monitored with this kit (considerably less in direct sunlight). Recommended for indoor use.

The kit consists of two separate PCBs - a transmitter board and a receiver board.

Specifications
Supply voltageRegulated 12Vdc (Order Code 660.446UK)
Current consumption~ 65mA approx (relay active)
Output1 x SPDT Relay
Maximum Output
Load (Resistive)
Up to 48Vac or 28Vdc @ 2 Amp max. (Relay Datasheet)
Relay ConnectionsNO, NC, C (Relay FAQ)
Dimensions (mm)Transmitter: ~30 x 24 x 15
Receiver: ~48 x 51 x 25
Fixing HolesM3
Board ConnectionsPower: 5.5 x 2.5mm DC sockets
Relay: Screw terminal block
Product FormatElectronic soldering kit (KT) or
Pre-assembled module (AS) Product Formats Info
DocumentationUser Manual
